PR9142 Portable Hydraulic Pressure Calibration Pump

PR9142 Portable Hydraulic Pressure Calibration Pump

PR9142 Portable Hydraulic Pressure Calibration Pump Pressure Range: 0~1000 bar Other name: Pressure source, pressure calibration, pressure comparator, pressure generator.

Overview:

New portable hydraulic pressure calibration pump, the product structure is compact, easy to operate, smooth pressure rise, stable voltage speed, medium filter using level, ensures oil cleanliness, prolongs equipment service life. This product volume is small, the pressure adjustment range is wide, pressure rise and effort, the best pressure source field.

Model

Portable Hydraulic Pressure Comparison Pump

Technical Indicators

Usage Environment

On-site or Laboratory

Pressure Range

PR9142A (0 ~ 600) bar

PR9142B (0 ~ 1000) bar

Adjustment Fineness

0.1 kPa

Working Medium

Transformer Oil or Pure Water

Output Interface

M20 x 1.5 (two) (optional)

Dimensions

360 mm * 220 mm * 180 mm

Weight

3 kg
